Quick Details

  • Type: Digital Printer
  • Condition: New
  • Plate Type: FDM 3D printer
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Alunar
  • Model Number: M508
  • Usage: Other
  • Automatic Grade: Semi-Automatic
  • Color & Page: Multicolor
  • Voltage: 110V/220V
  • Gross Power: 240W
  • Dimensions(L*W*H): 450*400*440mm
  • Weight: 10kg
  • Certification: CE/FCC/ROHS
  • After-sales Service Provided: Overseas third-party support available
  • Printing technology: FDM 3d printer
  • Structure: 8mm Acrylic
  • Control board: Marlin firmware MEGA 2560 chip
  • Best Print size: 200*200*180mm
  • Display: LCD 2004 Screen
  • Layer Thickness: 0.1-0.3mm
  • Nozzle diameter: 0.3mm [0.015 Inch]
  • Nozzle tempreture: 160-260 degree
  • Print Platform material: MK3 Aluminum
  • Printing Material: 1.75mm PLA ABS HIPS PA PVA WOOD TPU etc

Packaging & Delivery

Packaging Details Machine size:450*400*440mm
Package size:500*460*170mm
Net weight:8.5kg
Gross weight:10kg
Delivery Time 2-3 days for sample order,10-15 days for mass product

High Accuracy CNC Self-assembly diy kit 3d printer in Industry and Education

Product Description

Bigger build volume – 7200 cm3 (20 x 20 x 18 cm or 7.87 x 7.87 x 7.08 in)
Open frame design for easy use
Integrated LCD and SD card controller (8GB included)
ATMEGA 2560 chip Merlin firmware 1.4 version control board
0.3 mm nozzle (easily changeable) for 1.75 mm filament
Layer height from 0.1 mm
Heatbed with cold corners compensation – for warpless 3D printing from any material
Automatic skew axes compensation
Supported materials – PLA, ABS, PET, HIPS, Flex PP,Ninjaflex, aywood, Nylon,Bamboofill,Bronzefill,Carbon-fibers enhanced filaments……
Easy multicolor printing based on layer height
0.25 kg (0.55lbs) PLA filament included
exterior dimensions 49 x 45 x 15.5 cm (19.2 x 17.7 x 6.1 inches), weight 9.5 kg (20 lbs), CE & ROHS & FCC certification
Specially optimized firmware for quiet printing





Technique DataParameter
BrandALUNAR
ModelM508
Frame8mm acrylic (black)
Printing TechnologyFDM
Best Printing size200*200*180mm(7.87*7.87*7.08 inch)
Number of ExtruderSingle
Nozzle Diameter0.3mm(default)
Printing Precision0.1-0.3mm
Display2004 LCD
Printing speed40-120mm/s
XY Axis speed3000mm/s(max)
Z Axis speed200mm/s(max)
Nozzle Temperature170-260 degree (max)
Hot Bed Temperature100 degree(max)
Print Platform materialMK3 Aluminum
Filament1.75 mm PLA/ABS/HIPS/WOOD/TPU
Power Requirement InputAC110/220 50/60Hz
Out putDC 12V 20A
Operating systemWindows,Mac.Linux
Control SoftwareRepetier-Host.Cura
File formatSTL.G-CODE
InterfaceUSB/SD card(support offline print)
Working condition10-40 degree
LanguageEnglish
Machine size450*400*440mm
Packing size500*460*170mm
Machine weight8.5kg
Gross weight10kg




Package & Shipping

   PACKAGE:

Package size:500*460*170mm           Gross weight:10kg     Package type:all parts in a solid carton

DELIVERY TIME:

2-3 days for sample order,10-15 days for mass product,detail delivery date should be decided according to
production season and order quantity.

Certifications

CERTIFICATE

Strength proof

All our products are passed the inspection standards included CE,FCC.ROHS with 100% quality.

Company Information

ABOUT US

  • Our company has more than 30 employees and includes 1000 sqm manufacturing area.  We focus on desktop 3D printer field for 4 years and provide printers for many companies and countries. Our business mode is flexible, we have Alibaba/Aliexpress/Amazon, we have our own brand-ALUNAR and INFITARY, OEM/ODM are also welcomeVIEW MORE>>
